SONY/SHARP Color CCD
IR LED: ￠5X36PCS ,IR LED working Distance: 30M
Back Light Compensation(BLC)
Auto White Balance(AWB)
Lens: 4-9mm Manual Zoom Lens
Dimension : ￠131 x 93(H) mm

1/3" SONY ICX639BK CCD

700TV Lines Low Illumination, DWDR, OSD

PAL:795 (H)× 596(V) NTSC :811 (H) ×508 (V)

TV System     PAL/NTSC
IR LED     ￠5 X 36 PCS
IR Series Distance     30 M
Lens     4-9mm Manual Zoom Lens
Sync System     Internal
IR Status     Under 10 Lux By CDS

Usable Illumination  -  0.0005Lux/F2.0

IR Power On     CDS Auto Control

S/N Ratio  ≥54dB (AGC OFF)

Video Out     Composite Signal (1.0Vp-p, 75Ω)
Scanning System     PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Electronic Shutter Time     Auto:PAL 1/50-1/100,000Sec;NTSC 1/60-1/100,000Sec
Operation  Temperature     -10℃ ~ +50℃ RH95% Max
Storage  Temperature     -20℃ ~ +60℃ RH95% Max
White Balance     Auto
Power Source     DC12V 400mA
Dimension     ￠131 x 93(H) mm
Weight     800g
